Multi-point lock with round bolts KFV BS2300 W000 (old milling)

Multi-point lock with round bolts KFVBS2300 W000 (old milling)

Manufacturer – KFV (Germany)

multi-point lock with 3 locking points milling type W000 (old model) all bolts and latches are handle-operated suitable for both left and right hand doors anti-intruder protection with multiple bolts anti-intruder protection with multiple bolts compatible with standard door hardware main lock compatible with profile cylinder and has 2 auxiliary locks on either side, with round steel bolts backset D: 45 mm centre distance: 92 mm key-retractable latch, double throw bolt projection: 20 mm main lock with lined holes for screws up to M6 - for fixing backplate into its place handle spindle hole: 8 mm main lock case heigh: 207,5 mm, case thickness: 16 mm; distance from the cylinder centre to the back of the case: 17,5 mm all locking components are bright nickel-plated, all lock cases - galvanised and closed light galvanised face plate: 16 x 3 mm upper/lower lock case heigh: 130 mm, depth: 42,5 mm round bolts: Ø11mm, centered, projection19,5 mm Dimensions A Total length (mm) B Distance from the handle center to the center of the lower lock case (mm) C Distance from the handle center to the enter of the upper lock case  (mm) G Distance from the handle center to the bottom (mm) I Max. shortening of the upper part of the face plate (mm) K Max. shortening of the lower part of the face plate  (mm) 2170 760 730 1042 298 92

Security features

• round horizontal steel bolt prevents intruders from prising the door open
• tempered steel elements notably improve lock durability
• main lock deadbolt is secured against sawing and thus hinders break-in attempts
• corresponds with DIN V 18103 (ET1, ET2, ET3) standards for doors with anti-intruder protection

Advantages

• the tight seal provides reduced noise and better heat insulation
• door tightening ensures an optimal seal to prevent draughts
• smooth latch-lever mechanism is easy to use
• the lock retains its perfect functionality even after prolonged and intensive use
• the patented technology guarantees easy and accurate fitting

Areas of use

• for residential front doors, and for basement and back doors
• for apartment doors
• for extra high interior doors
• and in other areas where doors tend to warp and require a high level of security

Compatible strike plates
Separate strike plates

• central 19-267 + upper/lower 2300-08-20-1R
• central 15-530E + upper/lower 3615-530Q/31
• central 19-504 V + upper/lower 2319-504V
• central 19-503 V + upper/lower 3619-503V-31
• central 19-512V + upper/lower 2319-512V
• central SLK 881-083 A /DZM 402-00031 + upper/lower SLK 2600-267-2W/31
• central 8050-752ERH
• upper/lower 2330-03-20R vai 2500-03-20R

Locking rails

• BD25-2-230ERQH/31 B001
• BS60-230ERQH/31

TECHNICAL DOCUMENTATION

KFV BS 2200, BS 230X, BS 25XX - multi-point locks with 130 mm additional housing height - assembly instructions (ENG)

KFV BS 2200, BS 230X, BS 25XX - multi-point locks with 130 mm additional housing height - operating instructions (ENG)
